Customize Your Osburn Horizon Wood Fireplace

Customizing a product with us is simple and flexible. Following these steps, you can easily customize a product to meet your needs.


Instructions:
1. Choose a base product model.
2. Explore available options.
3. Select choices to view the total price.
4. Add the customized product to the cart and checkout.

Status: In Stock

US$5,099.00
Stove

Osburn Horizon Wood Fireplace (US$5,099.00)
Faceplate (Required)

Osburn Prairie Style Faceplate, Horizon (US$750.00)
Optional

Osburn Fresh Air Intake Register W/ Airtight Damper 5" (US$250.00)
Osburn Classic Moulded Refractory Brick Panels, Horizon (US$650.00)
Main Item Price US$ 0.00
Optional Item Price US$ 0.00
Price for this Configuration US$ 0.00

Description

Description

Immerse yourself in the captivating warmth and timeless beauty of the Horizon Wood Fireplace by Osburn Manufacturing. As a leading name in the industry, Osburn has crafted this exceptional fireplace to redefine your home heating experience. The Horizon combines cutting-edge technology, impeccable craftsmanship, and striking design to create a truly remarkable focal point for any living space.

With its sleek and contemporary aesthetic, the Horizon Wood Fireplace effortlessly blends into modern interiors while adding a touch of elegance. Its clean lines, large glass viewing area, and minimalist styling allow the mesmerizing flames to take center stage, creating a visually stunning ambiance that will leave you in awe.

But the Horizon is not just about aesthetics. It offers an unparalleled heating performance that will keep you cozy and comfortable throughout the seasons. Designed for efficiency, this fireplace harnesses the power of wood-burning to provide a sustainable heating solution. It maximizes heat output while minimizing fuel consumption, making it both environmentally friendly and cost-effective.

Equipped with advanced features and technology, the Horizon Wood Fireplace ensures optimal convenience and ease of use. The innovative air wash system keeps the glass clean, offering an unobstructed view of the flames, while the precise control mechanism allows you to easily adjust the heat output to your desired level of comfort.

Experience the warmth, charm, and energy efficiency of the Horizon Wood Fireplace by Osburn Manufacturing. Embrace the perfect blend of style and functionality, and create an inviting atmosphere that will leave a lasting impression on both family and friends. Upgrade your home heating solution and transform your living space into a cozy sanctuary with the Horizon Wood Fireplace.

Features

Features

  • Fuel type: Dry cordwood
  • Recommended heating area (sq. ft.): 1,000 - 2,800
  • Overall firebox volume: 4.28
  • EPA loading volume (cu. ft.): 4.28
  • Maximum burn time: 11 h
  • Maximum heat output (dry cordwood): 95,000 BTU/h (27.8 kW)
  • Overall heat output rate (min. to max.): 16,610 BTU/h (4.9 kW) to 43,021 BTU/h (12.6 kW)
  • Average overall efficiency (EPA cribs/Douglas fir): N.A. (HHV) N.A. (LHV)
  • Average overall efficiency (dry cordwood): 63.9% (HHV) 68.4% (LHV)
  • Optimum efficiency: 69.7%
  • Average particulate emissions rate: 1.6 g/h
  • Average CO: 157.4 g/h

Values are as measured per test method, except for the recommended heating area, firebox volume, maximum burn time and maximum heat output.

Recommended heating area and maximum burn time may vary subject to location in home, chimney draft,heat loss factors, climate, fuel type and other variables. The recommended heated area for a given appliance is defined by the manufacturer as its capacity to maintain a minimum acceptable temperature in the designated area in case of a power failure.

The maximum heat output (dry cordwood) is based on a loading density varying between 15 lb/ft³ and 20 lb/ft³. Other performances are based on a fuel load prescribed by the standard. The specified loading density varies between 7 lb/ft³ and 12 lb/ft³. The moisture content is between 19% and 25%.

(Average Overall Efficieny) As measured per CSA B415.1-10 stack loss method.

(HHV) Higher Heating Value of the fuel.

(LHV) Lower Heating Value of the fuel.

Performances based on a fuel load prescribed by the standard at 7 lb/ft³ and with a moisture content between 19% and 25%.

Optimum overall efficiency at a specific burn rate (LHV).

 This appliance is officially tested and certified by an independent agency.



Specifications

Specifications

Combustion technology: Non-catalytic
High-efficiency certified appliance: Yes, EPA 2020 approved
Maximum log length: 25"
Log positioning: Over width
Chimney diameter: 8"
Flue outlet diameter: 8"
Type of chimney: CAN/ULC S604, UL 103 (1700 °F) - CAN/ULC S629, UL 103 HT (2100 °F)
Minimum chimney height (feet): 15'
Baffle type: C-Cast
Approved for a mobile home installation: No
Shipping Weight: 550 lb (250 kg)
Door type: Double, glass with cast iron frame
Glass type: Ceramic glass
Glass surface – dimensions (Width X Height): 29 3/4" X 13 1/2"
Glass air-wash system: Yes
Premium quality blower included (CFM): 176
Overall dimension (Height): 43 3/8"
Overall dimension (Width): 50 3/4"
Overall dimension (Depth): 31 3/4"
Door opening – dimension (Height): 12 3/4"
Door opening - dimension (Width): 33"
Firebox – dimension (Height): 17"
Firebox – dimension (Width): 25 3/8"
Firebox – dimension (Depth): 17 7/8"
Moulded refractory bricks: Yes
Stainless-steel secondary-air system improving gas combustion: Yes
USA standard (emissions): EPA / ASTM WK47329
Canadian Standard (emissions): CSA B415.1-10
USA standard (safety): UL 127
Canadian standard (safety): ULC-S610
Tested and listed as per applicable standards: By an accredited laboratory (CAN/USA)
Warranty: Limited lifetime

Minimum clearances to combustibles*
(Data expressed in inches. 1 inch = 25.4 mm)

                                                                                                                     Canada   USA

Clearance – top (measured from the platform on which the appliance is installed)** 84" 84"
Clearance – combustible side mantle to unit 8" 8"
Clearance – side wall 24" 24"

* The information given on the certification label affixed to the appliance always overrides the information published in any other media (owner's manual, catalogues, flyers, magazines and/or web sites).

** Some appliances have been tested with a low ceiling. Before setting up your unit, refer to the installation manual.
