Customize your Osburn 2000 Wood Insert

Customizing a product with us is simple and flexible. Following these steps, you can easily customize a product to meet your needs.


Instructions:
1. Choose a base product model.
2. Explore available options.
3. Select choices to view the total price.
4. Add the customized product to the cart and checkout.

Status: In Stock

US$2,729.00
Stove

Osburn 2000 Wood Insert (US$2,729.00)
Faceplate (Required)

Osburn Faceplace Regular, 2000 Insert (US$150.00)
Osburn Black Faceplate Trims (29" X 44"), 1700, 2000 (US$120.00)
Osburn Brushed Nickel Faceplate Trims (29" X 44")1700, 2000 (US$120.00)
Osburn Black Steel Door Overlay, 2000 (US$100.00)
Osburn Brushed Nickel Steel Door Overlay, 2000 (US$300.00)
Optional

Osburn Fire Screen, Matrix , 2000 (US$180.00)
Osburn Fresh Air Intake Register W/ Airtight Damper 5" (US$250.00)
Osburn Part Liner Offset Adaptor (US$225.00)
Main Item Price US$ 0.00
Optional Item Price US$ 0.00
Price for this Configuration US$ 0.00

Description

Description

Elevate your home heating experience with the 2000 Wood Insert by Osburn Manufacturing. This impressive fireplace insert combines advanced technology, exceptional performance, and timeless design to provide you with efficient and stylish warmth. Designed to fit seamlessly into your existing fireplace, the 2000 Wood Insert brings new life to your space while offering superior heating capabilities.

With its large glass viewing area, the 2000 Wood Insert offers a captivating display of dancing flames that will mesmerize you and your guests. Enjoy the cozy ambiance and comforting warmth as this insert efficiently heats your home. Its innovative combustion system ensures optimal heat output while minimizing fuel consumption, making it an environmentally conscious and cost-effective heating solution.

Crafted with meticulous attention to detail, the 2000 Wood Insert showcases a sleek and modern design that complements any décor. Its clean lines, customizable trim options, and premium finishes allow you to personalize the insert to match your style and enhance the aesthetic appeal of your room. Experience the perfect combination of functionality and elegance with this beautifully crafted fireplace insert.

Installation of the 2000 Wood Insert is straightforward, thanks to its adaptable design and flexible venting options. With precise controls for adjusting heat output, you have full control over the temperature and comfort of your living space. Say goodbye to drafty fireplaces and embrace the efficient warmth and contemporary style of the 2000 Wood Insert by Osburn Manufacturing. Upgrade your fireplace and create a cozy sanctuary where lasting memories are made.

A Tax Credit is available for this product!

Features

Features

  • Fuel type: Dry Cordwood
  • Recommended heating area (sq. ft.): 500-2,100
  • Firebox volume (cu. ft.): 2.4
  • Maximum burn time: 8h
  • Maximum heat output (dry cordwood): 75,000 BTU/h (22.0 kW)
  • Overall heat output rate (min. to max): 14,800 BTU/h (4.34 kW) to 28,600 BTU/h (8.38 kW)
  • Average overall efficiency (EPA cribs / Douglas fir): N.A (HHV) N.A (LHV)
  • Average overall efficiency (dry cordwood): 69% (HHV) 74% (LHV)
  • Optimum efficiency: 77%
  • Average particulate emissions rate: 1.54 g/h
  • Average CO: 89.4 g/h

Values are as measured per test method, except for the recommended heating area, firebox volume, maximum burn time and maximum heat output.

Recommended heating area and maximum burn time may vary subject to location in home, chimney draft,heat loss factors, climate, fuel type and other variables. The recommended heated area for a given appliance is defined by the manufacturer as its capacity to maintain a minimum acceptable temperature in the designated area in case of a power failure.

The maximum heat output (dry cordwood) is based on a loading density varying between 15 lb/ft³ and 20 lb/ft³. Other performances are based on a fuel load prescribed by the standard. The specified loading density varies between 7 lb/ft³ and 12 lb/ft³. The moisture content is between 19% and 25%.

(Average overall efficiency) As measured per CSA B415.1-10 stack loss method.

(HHV) Higher Heating Value of the fuel.

(LHV) Lower Heating Value of the fuel.

Performances based on a fuel load prescribed by the standard at 7 lb/ft³ and with a moisture content between 19% and 25%.

Optimum overall efficiency at a specific burn rate (LHV).

This appliance is officially tested and certified by an independent agency.

Specifications

Specifications

Combustion technology: Non-catalytic
High-efficiency certified appliance: Yes, EPA 2020 approved
Maximum log length: 20"
Log positioning: Over width
Chimney diameter: 6"
Type of chimney: Liner - ULC-S635, CAN/ULC-S640, UL1777
Baffle type: C-Cast
Approved for a mobile home installation: No
Shipping Weight: 407 lb (185 kg)
Door type: Single, glass with cast iron frame
Glass type: Ceramic glass
Glass surface – dimensions (Width X Height): 17 1/8" X 10 1/4"
Glass air-wash system: Yes
Premium quality blower included (CFM): 120
Overall dimension (Height): 23 1/8"
Overall dimension (Width): 28 3/8"
Overall dimension (Depth): 26 3/8"
Door opening – dimension (Height): 9"
Door opening - dimension (Width): 17 1/2"
Firebox – dimension (Height): 11 7/8"
Firebox – dimension (Width): 21"
Firebox – dimension (Depth): 16 3/4"
Firebox lined with refractory bricks for better heat distribution: Yes
Stainless-steel secondary-air system improving gas combustion: Yes
Adjustable threaded legs: Yes
Steel thickness – body: 3/16"
Steel thickness – top: 5/16"
Fireplace opening – minimum (Height): 23 3/8"
Fireplace opening – minimum (Width): 28 7/8"
Fireplace opening – minimum (Depth): 15 3/4"
USA standard (emissions): Comply with EPA 2020
Canadian Standard (emissions): CSA B415.1-10
USA standard (safety): UL 1482, UL 737
Canadian standard (safety): ULC S628
Tested and listed as per applicable standards: By an accredited laboratory (CAN/USA)
Warranty: Limited lifetime

Minimum clearances to combustibles*
(Data expressed in inches. 1 inch = 25.4 mm)

                                                                                                                       Canada   USA

Clearance – top (measured from the platform on which the appliance is installed)** 84" 84"
Clearance – combustible side mantle to unit 9" 9"
Clearance – combustible top mantle to unit 27" 27"
Clearance – combustible side wall to unit 16" 16"
Clearance – minimum floor protection in front of the appliance 18'' 16''
Clearance – top shelf to unit 27" 27"

* The information given on the certification label affixed to the appliance always overrides the information published in any other media (owner's manual, catalogues, flyers, magazines and/or web sites).

** Some appliances have been tested with a low ceiling. Before setting up your unit, refer to the installation manual.
