Osburn 1700 Wood Insert

The Osburn 1700 Wood Insert, part number OB01705, is a compact wood-burning fireplace insert designed to upgrade an existing masonry fireplace into an efficient heating system. It delivers up to 65,000 BTUs of heat and is suited for warming small to medium living spaces. The insert features a durable steel firebox with a design that supports steady heat output and efficient fuel use.

Harnessing the power of wood-burning technology, the 1700 Wood Insert efficiently converts your fireplace into a reliable heat source. Its advanced combustion system ensures maximum heat output while minimizing fuel consumption, making it a sustainable and cost-effective option for heating your home. Say goodbye to drafty fireplaces and hello to efficient warmth that radiates throughout your living space.

Not only does the 1700 Wood Insert excel in performance, but it also adds a touch of elegance to your home. Its sleek lines, large viewing window, and versatile design seamlessly integrate with any décor, creating a focal point that enhances the ambiance of your room. The captivating flames dance behind the clear glass, providing a cozy and inviting atmosphere for you and your loved ones to enjoy.

Installation of the 1700 Wood Insert is a breeze, thanks to its flexible design and customizable options. It effortlessly fits into most standard fireplace openings, allowing for a seamless transition from your old fireplace to this modern heating solution. With various trim options and finishes available, you can personalize the insert to match your aesthetic preferences and complement your home's style.

This wood insert uses a non-catalytic combustion system and includes a blower to help circulate warm air throughout the room. The firebox is lined with high-density refractory bricks to improve heat retention and combustion efficiency. A cast iron door with ceramic glass and an air-wash system provides a clear view of the fire while maintaining cleaner glass during operation.

Upgrade your outdated fireplace with the efficiency and elegance of the 1700 Wood Insert. Embrace the warmth, convenience, and cost savings that this remarkable insert offers. Transform your living space into a cozy haven where cherished memories are made, all while reducing your environmental footprint. Experience the perfect combination of functionality and beauty with the 1700 Wood Insert by Osburn Manufacturing.

What’s Included: Wood insert unit with integrated blower and firebox components.

Installation Limits: Designed for installation inside an existing masonry fireplace using an approved chimney liner system.

Compatibility: Compatible with 6-inch chimney liner systems and approved wood insert venting installations.

Required Accessories:

Requires the addition of one each of (A) and (B) required accessories to complete the unit

A:

• OA10249  Black Door Overlay
• OA10250  Brushed Nickel Door Overlay

B:

• OA10116  Regular Faceplate (29" X 44")

Options:

• OA10122  Black Faceplate Trims (29" X 44")
• OA10123  Brushed Nickel Faceplate Trims (29" X 44")

• Compact wood fireplace insert designed for existing masonry fireplaces
• Up to 65,000 BTU heating capacity for small to medium spaces
• Non-catalytic combustion system for efficient wood burning
• Firebox lined with high-density refractory bricks
• Integrated blower improves heat circulation
• Cast iron door with ceramic glass viewing area and air-wash system
• Fuel type: Dry cordwood
• Recommended heating area (sq.ft.): 500-1,800
• Firebox volume (cu. ft.): 1.9
• Maximum burn time: 6 h
• Maximum heat output (dry cordwood): 65,000 BTU/h (19 kW)
• Overall heat output rate (min. to max.): 15,650 BTU/h (4.6 kW) to 23,300 BTU/h (6.83 kW)
• Average overall efficiency (EPA cribs / Douglas fir): N.A (HHV) N.A. (LHV)
• Average overall efficiency (dry cordwood): 70% (HHV) 75% (LHV)
• Optimum efficiency: 78%
• Average particulate emissions rate: 1.26 g/h
• Average CO: 58 g/h

Values are as measured per test method, except for the recommended heating area, firebox volume, maximum burn time and maximum heat output.

 Recommended heating area and maximum burn time may vary subject to location in home, chimney draft,heat loss factors, climate, fuel type and other variables. The recommended heated area for a given appliance is defined by the manufacturer as its capacity to maintain a minimum acceptable temperature in the designated area in case of a power failure.

The maximum heat output (dry cordwood) is based on a loading density varying between 15 lb/ft³ and 20 lb/ft³. Other performances are based on a fuel load prescribed by the standard. The specified loading density varies between 7 lb/ft³ and 12 lb/ft³. The moisture content is between 19% and 25%.

As measured per CSA B415.1-10 stack loss method.

Higher Heating Value of the fuel.

Lower Heating Value of the fuel.

Performances based on a fuel load prescribed by the standard at 7 lb/ft³ and with a moisture content between 19% and 25%.

Optimum overall efficiency at a specific burn rate (LHV).

This appliance is officially tested and certified by an independent agency.
