Toyotomi Laser 534 Graphite Wi-Fi Model Bluetooth Model

Toyotomi Laser 534 Graphite Wi-Fi Model Bluetooth Model

L-534

Heating Area: 750 - 1,150 sq ft

Status: In Stock

US$1,959.00

Qty:

Special Handling Required: Yes

Add To Compare

Description

Introducing the Toyotomi Laser 534 Direct Vent Oil Heater - the perfect heating solution for your home or office. With its advanced technology and innovative design, this heater delivers efficient and reliable warmth, while also being eco-friendly.

The Laser 534 features a direct vent design that eliminates the need for a chimney, making installation a breeze. The heater's compact size and contemporary design ensure it will complement any room decor. Additionally, this heater is equipped with an LCD display that provides clear and easy-to-read information, as well as a programmable timer that allows you to customize your heating needs.

The Laser 534 has an impressive heating capacity of up to 22,000 BTU per hour, ensuring that even the coldest spaces will be warm and cozy. The heater also has an automatic shut-off feature that kicks in if the unit tips over, ensuring your safety.

With its high-efficiency operation and low fuel consumption, the Laser 531 or 532 is both cost-effective and environmentally friendly. Its clean-burning technology reduces emissions and produces less soot, ensuring cleaner air for you and your family.

The new Wi-Fi-compatible Laser 534 comes from Toyotomi, the leader for over 30 years in direct vent heaters. The Toyotomi Laser 534 gives your home a central heating system that comes at far less cost. Additionally, the Toyostove Laser 534 has a best-in-class 87% efficiency rating. This means cost savings without sacrificing heating comfort. With great flexibility, use the Laser 534 for either a supplemental heating source or as primary heat for basements, garages, and seasonal cottages. It has proven to be not only highly efficient but also safe and reliable.

The Toyotomi Laser 534 is one of the most fuel-efficient heating solutions on the market today. The special stainless steel heat exchanger carries the highest efficiency code and an 87% efficiency rating, providing more heat for your dollars. The cost to operate a Toyotomi oil heating system is so economical that many owners enjoy annual savings of up to 70% over electric heating, 60% over propane heating, and 40% over traditional oil and natural gas heating systems. The Laser 534 pays for itself in fuel savings in just a few short years.

If you're looking for an efficient and reliable heating solution for your home or cabin, the Toyotomi Laser 534 Direct Vent Oil Heater is a perfect choice.

Features

EFFICIENT AND ECONOMICAL
Toyotomi Laser products are the most fuel-efficient, energy-saving, oil* heating systems available.

Uses up to 50% less fuel for heating comparable size areas than conventional oil-fired heating systems at a fraction of the cost
The only oil-fired modulating burner in North America
(increases efficiency)
Pays for itself in fuel savings in just a few short years

COMFORTABLE AND WI-FI/BLUETOOTH COMPATIBLE
The Laser series large circulation fan distributes heat quickly and evenly in order to maintain and optimize maximum comfort.

Automatically regulate between low, medium and high-temperature settings
New Wi-Fi feature allows changing temperature remotely
from an app on your Apple or Android device
Self shut-off when room rises approximately 4° above the desired temperature

CLEAN, SAFE & ODORLESS
Advanced heating pipe-within-a-pipe forced flue venting system creates smokeless, odorless, clean heating.

Lower emissions (up to 50% less CO2) than conventional oil-fired heating systems
Outside pipe brings in outside air for combustion
Inside pipe exhausts all combustion by-products to the outside
Circulating fan distributes heat
Cool-to-the-touch cabinet
Permanent mesh filter protects circulation fan and interior components from dust

EASY INSTALLATION
Owner's manual provides complete, step-by-step instructions that are helpful and easy to understand.

Installation takes about three hours, or less
Vents through a side wall using the direct vent kit which is included with heater
Full range of optional parts and accessories available offers a variety of different installations

FLEXIBLE FUEL OPTIONS
Toyostove Vented Heaters can use the following fuels without any modifications to the unit:

Ultra Low Sulfur Heating Oil (ULSHO)
Ultra Low Sulfur Diesel (ULSD)
#1 Low Sulfur Fuel Oil, or K-1 Kerosene

Check with your local fuel oil dealer for which of these fuels are available in your area.

EXHAUST SYSTEM
The Laser Series flue pipe makes venting to the outside simple and easy. Completely flexible, it adjusts to wall thickness. A small vent cap is all that can be seen from the outside.

SET-BACK
Weekly Timer Operation allows for up to 30 different Set-Back temperatures. The Weekly Timer can be used to change the temperature for different days of the week and several times during the day.

Specifications

Fuel Type:	Ultra Low Sulfur Heating Oil (ULSHO) or Ultra Low Sulfur Diesel Fuel (ULSD) (ASTM D975 S15), Low Sulfur No. 1 Fuel (ASTM D396 S500), or K-1 Kerosene (ASTM D3699)
Heating Efficiency:	87% (AFUE Rating)
Heating Rating:	22,000 BTU/Hr (High) 15,000 BTU/Hr (Medium) 8,000 BTU/Hr (Low)
Fuel Consumption:	0.165 Gal/Hr (High) 0.113 Gal/Hr (Medium) 0.060 Gal/Hr (Low)
Size (WxHxD):	19-5/8" x 23-5/8" x 16-1/2"
Weight:	38 lbs (empty)
Heating Area: *	920 Sq. Ft. at (0°F) 1150 Sq. Ft. at (20°F)
Max. Length of Vent Pipe System:	Maximum 10 Ft., 3 bends or less
Electrical Rating:	120 Volts AC, 60 Hz Preheat: 240 Watts Burning: 40 Wattts
Vent Hole Pipe:	2-3/4" - 3" Diameter
Type of Tank:	Exterior Tank

* 0° F Heat Load = 24 BTU/ft²/hr
20° F Heat Load = 20 BTU/ft²/hr
Room size for which this heater is suitable will vary depending on outside temperature, house insulation, window size and other factors.

Literature

Heating with Oil versus Propane

Toyostove Laser and Oil Miser Vented Heating System Accessories

Toyotomi and Toyostove Registration

Support

Diagrams, Troubleshooting, and Support - Learn More

Q. What is the Toyotomi L-534 Laser 534 Graphite Wi-Fi Bluetooth Model best for?

A. The Toyotomi L-534 Laser 534 Graphite Wi-Fi Bluetooth Model is designed for dependable, high-efficiency heating in homes, cabins, workshops, and other medium-sized spaces in cold climates. Its direct-vent sealed combustion system delivers clean, consistent heat while helping reduce fuel consumption. With Wi-Fi connectivity, Bluetooth capability, and advanced electronic controls, it provides convenient comfort for homeowners who want reliable heating throughout the winter.

Q. Who should use the Toyotomi L-534 Laser Direct Vent Heater?

A. The Toyotomi L-534 is an excellent choice for rural homeowners, off-grid property owners, vacation cabin owners, contractors, and small commercial facilities requiring dependable oil-fired heating. It is engineered for demanding northern climates where efficiency, safety, and long-term reliability are priorities. Its combination of advanced controls and direct-vent operation also makes it well suited for energy-conscious homeowners upgrading older heating equipment.

Q. Can the Toyotomi L-534 efficiently heat a cabin or medium-sized home?

A. Yes. The Toyotomi L-534 is designed to efficiently heat medium-sized homes, cabins, garages, and similar spaces, with actual heating performance depending on insulation quality, ceiling height, floor plan, and outdoor temperatures. Its modulating burner automatically adjusts heat output to maintain steady indoor comfort while minimizing unnecessary fuel use.

Q. Is the Toyotomi L-534 suitable for homeowners and professional installers?

A. Yes. The Toyotomi L-534 features intuitive digital controls that are easy for homeowners to operate after installation, while its direct-vent design and installation accessories make it practical for professional HVAC installers. Installation should always follow the manufacturer's instructions and all applicable local building and fuel codes.

Q. How energy efficient is the Toyotomi L-534 Laser heater?

A. The Toyotomi L-534 is engineered for high fuel efficiency through its sealed combustion system, electronic burner management, and variable heat output. By adjusting fuel consumption to match heating demand, it helps reduce operating costs while maintaining consistent indoor temperatures. Actual fuel savings depend on installation quality, building construction, outdoor temperatures, and heating habits.

Q. What fuels are compatible with the Toyotomi L-534?

A. The Toyotomi L-534 is compatible with approved low-sulfur heating fuels including Ultra Low Sulfur Heating Oil, Ultra Low Sulfur Diesel, Low Sulfur No. 1 Fuel Oil, and K-1 kerosene. This flexibility makes it a dependable solution for rural and remote locations where available fuel types may differ throughout the year.

Q. Does the Toyotomi L-534 support Wi-Fi and Bluetooth remote control?

A. Yes. The Toyotomi L-534 includes built-in Wi-Fi and Bluetooth capability, allowing users to monitor and adjust heating settings from compatible mobile devices. Programmable scheduling and remote temperature management help improve comfort while reducing unnecessary fuel consumption when heating demands change.

Q. What accessories are available for the Toyotomi L-534?

A. The Toyotomi L-534 supports a wide range of installation and fuel system accessories including vent extensions, extension pipe kits, fuel line components, shut-off valves, lifter pumps, fuel filters, pressure reducing valves, and fuel tank accessories. These options allow installers to adapt the heater for a variety of building layouts and installation requirements.

Q. Is the Toyotomi L-534 quiet, safe, and suitable for everyday heating?

A. Yes. The Toyotomi L-534 is built for quiet daily operation using a sealed direct-vent combustion system that draws combustion air from outdoors and vents exhaust outside. It also incorporates multiple electronic safety features, digital monitoring, a circulation fan, and a removable air filter to help provide dependable performance throughout the heating season.

Q. How does the Toyotomi L-534 compare with traditional oil-fired heaters?

A. Compared with many traditional oil-fired heaters, the Toyotomi L-534 offers improved fuel efficiency, advanced electronic controls, Wi-Fi connectivity, cleaner sealed combustion, and more precise temperature management. Its compact direct-vent design makes it an excellent option for homeowners seeking dependable, energy-efficient heating without the complexity of a larger central oil heating system.
