Toyotomi Laser 733 Wi-Fi Bluetooth Model

L-733

Heating Area: 1,400 - 2,000sqft

Status: In Stock

US$2,739.00

Special Handling Required: Yes

Description

Description

The Toyotomi Laser L-733 is a high-efficiency, direct-vent oil heater that can heat up to 2,000 square feet. It features a sleek, modern design and advanced technology for easy operation and maximum energy efficiency.

The Laser L-733 uses a direct vent system that draws in outside air for combustion and vents exhaust gases outside, making it safe for indoor use. It has a high thermal efficiency rating of 86%, which means it can produce more heat with less fuel.

This oil heater has a user-friendly digital control panel that allows you to set the temperature and timer functions. It also has a programmable thermostat that can be set to turn on and off automatically based on your schedule, saving you money on your energy bills.

The Laser L-733 has a heating capacity of up to 40,000 BTU per hour. It also features a safety shut-off switch that turns off the heater if it tips over or detects low oxygen levels.

Overall, the Toyotomi Laser L-733 is a reliable and efficient heating solution for homes and businesses, offering advanced features and a long-lasting design that provides comfortable warmth throughout the colder months.

The Toyotomi Laser L-733 is the largest output wall furnace available from Toyotomi. The Toyotomi Laser L-733; can heat up to 2000 Sq. Ft. of living space for a fraction of alternative heat sources. The heater is a sealed combustion unit or direct-vent system that uses only outside air for combustion and vents combustion gases directly to the outdoors. These modern high-efficiency models provide safe, comfortable warmth for zone heating or whole house heat. These new models are now Wi-Fi compatible. The revolutionary Toyotomi Laser Direct Vent Heaters, with their whisper-quiet comfort, safety and dependability, are the most popular, best-selling, direct vent heating systems in Alaska.

Features

Features

EFFICIENT AND ECONOMICAL
Toyotomi Laser products are the most fuel-efficient, energy-saving, oil* heating systems available.

  • Uses up to 50% less fuel for heating comparable size areas than conventional oil-fired heating systems at a fraction of the cost
  • The only oil-fired modulating burner in North America
    (increases efficiency)
  • Pays for itself in fuel savings in just a few short years

COMFORTABLE AND WI-FI/BLUETOOTH COMPATIBLE
The Laser series large circulation fan distributes heat quickly and evenly in order to maintain and optimize maximum comfort.

  • Automatically regulate between low, medium and high-temperature settings
  • New Wi-Fi feature allows changing temperature remotely
    from an app on your Apple or Android device
  • Self shut-off when room rises approximately 4° above the desired temperature

CLEAN, SAFE & ODORLESS
Advanced heating pipe-within-a-pipe forced flue venting system creates smokeless, odorless, clean heating.

  • Lower emissions (up to 50% less CO2) than conventional oil-fired heating systems
  • Outside pipe brings in outside air for combustion
  • Inside pipe exhausts all combustion by-products to the outside
  • Circulating fan distributes heat
  • Cool-to-the-touch cabinet
  • Permanent mesh filter protects circulation fan and interior components from dust

EASY INSTALLATION
Owner's manual provides complete, step-by-step instructions that are helpful and easy to understand.

  • Installation takes about three hours, or less
  • Vents through a side wall using the direct vent kit which is included with heater
  • Full range of optional parts and accessories available offers a variety of different installations

FLEXIBLE FUEL OPTIONS
Toyostove Vented Heaters can use the following fuels without any modifications to the unit:

  • Ultra Low Sulfur Heating Oil (ULSHO)
  • Ultra Low Sulfur Diesel (ULSD)
  • #1 Low Sulfur Fuel Oil, or K-1 Kerosene

Check with your local fuel oil dealer for which of these fuels are available in your area.

EXHAUST SYSTEM
The Laser Series flue pipe makes venting to the outside simple and easy. Completely flexible, it adjusts to wall thickness. A small vent cap is all that can be seen from the outside.

SET-BACK
Weekly Timer Operation allows for up to 30 different Set-Back temperatures. The Weekly Timer can be used to change the temperature for different days of the week and several times during the day.

Specifications

Specifications

Fuel Type: Ultra Low Sulfur Heating Oil (ULSHO) or Ultra Low Sulfur Diesel Fuel (ULSD) (ASTM D975
S15), Low Sulfur No. 1 Fuel (ASTM D396 S500), or K-1 Kerosene (ASTM D3699)
Heating Efficiency: 87% (AFUE Rating)
Heating Rating: 40,000 BTU/Hr (high)
27,000 BTU/Hr (medium)
15,000 BTU/Hr (low)
Size (WxHxD): 30" x 27-1/2" x 16-3/4"
Weight: 75 lbs (empty)
Fuel Consumption 0.301 gal/hr (high)
0.203 gal/hr (medium)
0.113 gal/hr (low)
Heating Area: * 1670 sq. Ft. at  (0°F)
2000 sq. Ft. at  (20°F)
Max. Length of
Vent Pipe System:
Maximum 10 ft., 3 bends or less
Electrical Rating: 120 Volts, 60 Hz
Vent Hole Pipe: 2-3/4" - 3" diameter
Type of Tank: Exterior Tank



* 0° F Heat Load = 24 BTU/ft²/hr
20° F Heat Load = 20 BTU/ft²/hr
Room size for which this heater is suitable will vary depending on outside temperature, house insulation, window size, and other factors.



Literature

Support

Support

Diagrams, Troubleshooting, and Support - Learn More


People Also Ask:

Q. What is the Toyotomi L-733 Laser 733 Wi-Fi Bluetooth Model best for?

A. The Toyotomi L-733 Laser 733 Wi-Fi Bluetooth Model is best for efficient whole-home or large-zone heating in homes, cabins, shops, and light commercial spaces up to about 2,000 square feet. Its direct-vent oil design uses outside air for combustion and vents exhaust outdoors, helping provide safe, clean, steady heat. With Wi-Fi compatibility, programmable temperature control, and up to 40,000 BTU/hr output, it is well suited for cold-climate properties where reliable warmth matters.

Q. Who should use the Toyotomi L-733 Laser Direct Vent Heater?

A. The Toyotomi L-733 is a strong fit for rural homeowners, off-grid property owners, contractors, and facility managers who need dependable oil-fired heat in larger spaces. It supports homes, cabins, businesses, and remote buildings where fuel efficiency, sealed combustion, and long-term reliability are important. It is especially useful where conventional oil-fired heating costs are high or where a direct-vent wall furnace is preferred over a larger central system.

Q. Can the Toyotomi L-733 heat a large home or cabin?

A. Yes, the Toyotomi L-733 can heat up to about 2,000 square feet, depending on outdoor temperature, insulation, windows, and building layout. It is rated for 40,000 BTU/hr on high, 27,000 BTU/hr on medium, and 15,000 BTU/hr on low. For colder conditions, the listed heating area is about 1,670 square feet at 0°F and about 2,000 square feet at 20°F.

Q. Is the Toyotomi L-733 suitable for beginners or professional installers?

A. The Toyotomi L-733 is designed for straightforward installation, but fuel, venting, and electrical work should be handled according to the owner’s manual and local code requirements. The heater includes a direct-vent kit and the manual provides step-by-step installation guidance. Many homeowners appreciate the simple digital controls, while contractors benefit from the direct-vent layout, accessory options, and service support.

Q. How efficient is the Toyotomi L-733 Laser 733 heater?

A. The Toyotomi L-733 has an 87% AFUE heating efficiency rating and is built to use fuel carefully through modulating burner operation. It can use up to 50% less fuel than conventional oil-fired systems for comparable heating areas. Actual savings depend on building insulation, fuel type, thermostat settings, outdoor temperature, and how the heater is installed and maintained.

Q. What fuels can the Toyotomi L-733 use?

A. The Toyotomi L-733 can use Ultra Low Sulfur Heating Oil, Ultra Low Sulfur Diesel, Low Sulfur No. 1 Fuel Oil, or K-1 kerosene without modifying the heater. This flexibility is helpful in rural and remote areas where fuel availability can vary by location. Customers should check with their local fuel oil dealer to confirm which approved fuels are available in their area.

Q. Does the Toyotomi L-733 support Wi-Fi and Bluetooth control?

A. Yes, the Toyotomi L-733 is Wi-Fi compatible and allows remote temperature changes from an Apple or Android device. It also includes digital controls, programmable thermostat functions, and weekly timer operation with multiple set-back temperatures. These controls help maintain comfort while reducing unnecessary fuel use when heat demand changes during the day or week.

Q. What accessories does the Toyotomi L-733 support?

A. The Toyotomi L-733 supports optional venting, fuel, and installation accessories for different wall thicknesses and fuel system layouts. Available accessories include flue pipe extensions, exhaust extension pipes, extension pipe sets, a Toyotomi lifter pump, fuel filter fittings, a fuel tank valve kit, a pressure reducing valve, shut-off valves, and fuel line components. These accessories help contractors and property owners adapt the heater to a range of installation conditions.

Q. Is the Toyotomi L-733 quiet, safe, and easy to live with?

A. Yes, the Toyotomi L-733 is designed for quiet comfort, clean operation, and safe indoor heating when installed correctly. Its pipe-within-a-pipe direct-vent system brings in outside combustion air and sends combustion by-products outdoors. It also includes a cool-to-the-touch cabinet, permanent mesh filter, circulation fan, and safety shut-off functions for dependable daily use.

Q. How does the Toyotomi L-733 compare to conventional oil-fired heating systems?

A. The Toyotomi L-733 is typically more efficient, more controlled, and easier to zone than many conventional oil-fired heating systems. Its direct-vent sealed combustion design supports clean indoor operation, while the modulating burner adjusts output between low, medium, and high heat levels. For rural homes, cabins, and remote buildings, that can mean steadier comfort, lower fuel use, and a smaller wall-furnace footprint compared with larger central oil systems.
